No121 1975
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| 150, later- P121 | China | 1974 | non-operational late 1990s | ||||
| 151, later- P122 | China | 1974 | non-operational late 1990s | ||||
| 152, later- P123, later- P115 | China | 1974 | non-operational late 2010s | ||||
| 650, later- P931, later- P421 | China | 1974 | non-operational late 1990s | ||||
| 651, later- P932, later- P422 | China | 1975 | non-operational late 1990s | ||||
| 652, later- P933, later- P423 | China | 1975 | non-operational late 1990s |
|
Displacement standard, t |
123 |
|
Displacement full, t |
135 |
|
Length, m |
38.8 |
|
Breadth, m |
5.41 |
|
Draught, m |
1.55 propellers |
|
No of shafts |
4 |
|
Machinery |
2 M-50F-4 diesels + 2 12D6 diesels |
|
Power, h. p. |
4200 (2x1200+2x910) |
|
Max speed, kts |
28.5 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
750(16.5) |
|
Armament |
2 x 2 - 37/63 type 61, 2 x 2 - 25/80 type 61M |
|
Sensors |
type 351 radar |
|
Complement |
36 |
Project history: Chinese project 062 patrol boats ('Shanghai II'), transferred without ASW armament.
Modernizations: 1990s, all: + 2 - 533 TT
Naval service: P123 defected to Italy in March 1997 but was returned at the end of the year.
© Ivan Gogin, 2019
