| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| 5 de Agosto, 2007- Isla Santa Rosa | LG35 | Moss Point Marine, Escatawpa, USA | 5.1991 | Coast Guard, in service (2019) | |||
| 27 de Febrero, 2007- Isla Puná | LG36 | Moss Point Marine, Escatawpa, USA | 11.1991 | Coast Guard, in service (2019) |
|
Displacement standard, t |
120 |
|
Displacement full, t |
190 |
|
Length, m |
31.6 pp 34.1 oa |
|
Breadth, m |
6.86 |
|
Draught, m |
2.14 |
|
No of shafts |
3 |
|
Machinery |
2 General Motors Detroit Diesel 16V149MTI diesels + 1 General Motors Detroit Diesel 16V92TAB diesel |
|
Power, h. p. |
2560 + 860 = 3420 |
|
Max speed, kts |
27 |
|
Fuel, t |
diesel oil |
| Endurance, nm(kts) | 1500(13) |
|
Armament |
1 x 1 - 40/60 Mk 3, 2 x 1 - 12.7/90 |
|
Electronic equipment |
Decca TM1226 radar |
|
Complement |
19 |
Project history: Built under U.S. Foreign Military Sales program for Galapagos Islands service. Carry a 10-person rigid inflatable inspection boat.
Modernizations: 2007-2008, both: - 1 x 1 - 40/60, Decca TM1226 radar; + 1 x 1 - 20/90 GAM-B01, Furuno radar
Naval service: No significant events.
Isla Santa Rosa 2002
