24 de Mayo 1978
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
| Quito, 1975- 25 de Julio, 2007- Isla Isabela | LC71, 1980- LGC31 | Peterson Builders, Sturgeon Bay, USA | 11.1.1965 | 10.1965 | Coast Guard 1980, stricken 2014 | ||
| Guayaquil, 1975- 8 de Agosto, 1978- 24 de Mayo | LC72, 1980- LGC32 | Peterson Builders, Sturgeon Bay, USA | 10.3.1965 | 10.1965 | collision 29.8.1995 |
|
Displacement standard, t |
130 |
|
Displacement full, t |
147 |
|
Length, m |
30.2 pp 30.8 oa |
|
Breadth, m |
6.45 |
|
Draught, m |
2.30 |
|
No of shafts |
4 |
|
Machinery |
8 General Motors 6-71 diesels |
|
Power, h. p. |
2200 |
|
Max speed, kts |
21 |
|
Fuel, t |
diesel oil 16 |
| Endurance, nm(kts) | 1000(12) |
|
Armament |
1 x 1 - 40/60 Mk 3, 2 x 2 - 20/70 Mk 24, 2 x 1 - 12.7/90 |
|
Electronic equipment |
Raytheon 1500B Pathfinder radar |
|
Complement |
15 |
Project history: USN PGM71 class.
Modernizations: 1989, 25 de Julio: was re-engined with 4 MTU diesels (3520hp, 17kts).
Naval service: 24 de Mayo was lost 29.8.1995 in collision with s/s Dole Ecuador.
1963
