1-go 1885
|
Names |
第1水雷艇 - 第4水雷艇 [1-go - 4-go] |
|
Builders |
Yarrow, Poplar, UK: 1-go - 4-go |
|
Commissioned |
1880: 1-go - 4-go |
|
Losses |
none |
|
Transfers |
none |
| Discarding | 1909-1910: 1-go - 4-go |
|
Displacement normal, t |
40 |
|
Displacement full, t |
|
|
Length, m |
29.4 pp 30.5 wl |
|
Breadth, m |
3.68 |
|
Draught, m |
0.99 |
|
No of shafts |
1 |
|
Machinery |
1 HC, 1 locomotive boiler |
|
Power, h. p. |
620 |
|
Max speed, kts |
22 |
|
Fuel, t |
coal |
| Endurance, nm(kts) | |
|
Armament |
2 x 1 - 37/20 1pdr Hotchkiss Mk I, 2 - 350 TT (bow), 1 x 1 - 350 TT |
|
Complement |
|
Project history: Designed by Sir Edward Reed on the basis of RN 100ft class.
Modernizations: None.
Naval service: No significant events.
No 2
Many thanks to Alexandr Isaenko for information provided
