| Name | No | Yard No | Builder | Laid down | Launched | Comm | Fate |
| ต.111 [Tor 111] | 111 | Marsun, Bangkok | 24.6.2012 | 7.2013 | 28.3.2014 | in service (2019) | |
| ต.112 [Tor 112] | 112 | Marsun, Bangkok | 24.6.2012 | 7.2013 | 28.3.2014 | in service (2019) | |
| ต.113 [Tor 113] | 113 | Marsun, Bangkok | 24.6.2012 | 7.2013 | 28.3.2014 | in service (2019) |
|
Displacement standard, t |
|
|
Displacement full, t |
200 |
|
Length, m |
36.0 |
|
Breadth, m |
7.60 |
|
Draught, m |
1.70 |
|
No of shafts |
3 |
|
Machinery |
3 Cummins KTA50M diesels |
|
Power, h. p. |
5400 |
|
Max speed, kts |
28 |
|
Fuel, t |
diesel oil |
|
Endurance, nm(kts) |
1200 |
|
Armament |
1 x 1 - 20/90 GAM-B01, 2 x 1 - 12.7/90 |
|
Electronic equipment |
2x Furuno radars |
|
Complement |
30 |
Project history: There is a place for SSMs.
Modernizations: None.
Naval service: No significant events.
© Ivan Gogin, 2019
